Element Optics Helix 6-24x50 FFP APR-2D 1/4 MOA Rifle Scope
- 30mm Main Body Tube
- Compact, Lightweight design
- First Focal Plane Reticle
- Aircraft Grade Aluminium
- Side Parallax: 10yds-Infinity
- Fully Multi-Coated Lenses
- Tool-free Resettable Turrets with 15 MOA per Revolution
- Hard Mechanical Zero-Stop
- Removable Magnification Throw Lever
- Waterproof, Fogproof, Shockproof & Nitrogen Purged
- Sunshade, Lens Cloth & Rubber Lens Caps included
Element Optics Helix 6-24x50 FFP MOA APR-2D Rifle Scope
Element Optics has designed the HELIX in a way that puts the important things first: clear glass, smart reticles, innovative features and a turret system superior to other products in the same price class.
The turret system has been upgraded from your stock-standard sporting optic to feature stainless steel internals for resistance against wear-and-tear when dialling regularly – something that modern shooting disciplines require. The tool-free turrets and zero-stop mechanism give you high-end features without breaking the bank, and the First Focal Plane reticle ensures precise reticle calibration at all magnifications.
Element Optics has introduced quality control checks to give you peace of mind when taking that 1000 yard shot, and if something goes wrong, their Platinum Lifetime Warranty has you covered!
Element Optics Helix 6-24x50 FFP MOA APR-2D Rifle Scope
| MAGNIFICATION RANGE | 6-24x |
| TUBE DIAMETER | 30mm |
| OBJECTIVE LENS DIAMETER | 50mm |
| EXIT PUPIL | 9.1-2.2mm |
| EYE RELIEF | 3.7 – 4 Inches |
| FIELD OF VIEW | @100yds: 18.3-4.6 ft |
| CLICK VALUE | 1/4 MOA (15 MOA / REV) |
| ELEVATION ADJUSTMENT RANGE | 65 MOA |
| WINDAGE ADJUSTMENT RANGE | 40 MOA |
| MINIMUM PARALLAX | 10 YDS |
| LENGTH | 14.3 Inches |
| WEIGHT | 26oz |
Element Optics Helix 6-24x50 FFP MOA APR-2D Rifle Scope
- 30mm Main Body Tube
- Compact, Lightweight design
- First Focal Plane Reticle
- Aircraft Grade Aluminium
- Side Parallax: 10yds-Infinity
- Fully Multi-Coated Lenses
- Tool-free Resettable Turrets with 15 MOA per Revolution
- Hard Mechanical Zero-Stop
- Removable Magnification Throw Lever
- Waterproof, Fogproof, Shockproof & Nitrogen Purged
- Sunshade, Lens Cloth & Rubber Lens Caps included
Element Optics Helix 6-24x50 FFP MOA APR-2D Rifle Scope
APR-2D 6-24 FFP MOA
DESIGN FEATURES
APR stands for “All-Purpose Reticle”, and that’s the concept behind the design of the APR
C & D variants. The “D” is the “dirty” more complex of the two, with holdover dots
extending down in a ‘Christmas Tree’ pattern for more precise long-range holds.
The fine centre dot draws your eye away from the distraction of the markings for those
who plan to dial instead of hold, but a whole host of features are there for those who wish
to make use of them.
MOA-SCALE:
The MOA Scale on the horizontal & vertical crosshairs allow the shooter to measure
objects downrange and quickly make adjustments. With one division equalling one click,
the guesswork is gone. This helps with ranging targets, and obtaining a quick zero.
EXTENSIVE HOLDOVER DOTS:
Holdover dots allow the shooter to hold with precision when there is no time to dial.
Extreme Long Range shooters can also accurately call points of impact and make quick
adjustments.
NUMBERED MARKINGS:
Numbers on both the horizontal and vertical axis allow shooters to quickly find hold points
in pressure situations like PRS/NRL matches.
TAPERED BARS:
Bars on the left, right & bottom of the reticle taper out to the edge of your field of view,
drawing your eye to the centre at all magnifications without becoming too thick or thin.
Element Optics Helix 6-24x50 FFP MOA APR-2D Rifle Scope
Platinum Lifetime Warranty
